‘HEAT-ZERO’ is architectural window film brand name of Filink. It blocks 99.9% UV rays as well as it provides heat protection, because it protects entire infrared ray. Also it can save your energy cost as retaining indoor temperature.
Nano Ceramic film
Ceramic sol based on nano dispersion technology which has been developed for years provides better heat protection than ordinary dyed films.
Great heat protection within whole infrared ray (781~2500nm)
Filink Solar control window film blocks maximum 99% entire of Infrared ray (781~2500nm) and good durability. Most of window films which has 99% Infrared ray protection utilize dye to maximize the number on specific area(900~1000nm) only. Also it doesn’t have good durability, because of dye.
Saving Energy Cost
Filink Nano Ceramic window film has good heat protection and good durability. It keeps indoor temperature not to allow heat coming in. It saves your heating or cooling cost.
Block more than 99% UV ray
Filink Solar control film blocks 99.9% UV ray which causes skin-ageing, skin cancer, and fading objects such as cloth, furniture, and electronics.
Good Durability
Ceramic nano dispersion technology improves durability and heat protection. It doesn’t have any problems with oxidation or fading.
Easy installation
Installation is easy, because base film is thin. However, our leading coating technology makes thick ceramic coating on thin base film. That’s why our film has good heat protection meantime it is easy installation with thin film.
Privacy protection and Keep the view from your place
Window film gives you more privacy. Meantime, you can keep outside view.
Holding shattered glass
Window film minimizes damage from scattering by Natural disaster or physical impact.
Architectural films
Specification
HEAT ECO
Nano Ceramic film is non-metal, non-dye product. This is standard window film which blocks UV rays, and infrared rays at entire range with reasonable price.
| PRODUCT |
Visible Light transmittance |
Visible Light Reflectance |
IR cut off rate at 950nm |
IR cut off rate at 781~2500nm |
Total Solar Energy Rejected |
Ultraviolet
cut off ratio |
| HEAT E05 |
6.8% |
4.5% |
61.8% |
76.8% |
64.2% |
>99% |
| HEAT E20 |
21.2% |
4.7% |
61.8% |
78.3% |
57.8% |
>99% |
| HEAT E35 |
33.4% |
5.6% |
61.83% |
77.7% |
54.5% |
>99% |
| HEAT E60 |
64.4% |
7.1% |
61.8% |
79.6% |
44.6% |
>99% |
HEAT PREMIUM
This is nano ceramic without metal, or dye components. This Premium window film blocks UV rays, and infrared rays at entire range.
| PRODUCT |
Visible Light transmittance |
Visible Light Reflectance |
IR cut off rate at 950nm |
IR cut off rate at 781~2500nm |
Total Solar Energy Rejected |
Ultraviolet
cut off ratio |
| HEAT P60 |
62.8% |
6.7% |
81.0% |
88.5% |
48.6% |
>99% |
| HEAT P70 |
71.4% |
7.7% |
80.4% |
83.1% |
43.4% |
>99% |
HEAT ROYAL
Nano ceramic window film has high VLT, high IR rejection. This is one of the best products in Filink.
| PRODUCT |
Visible Light transmittance |
Visible Light Reflectance |
IR cut off rate at 950nm |
IR cut off rate at 781~2500nm |
Total Solar Energy Rejected |
Ultraviolet
cut off ratio |
| HEAT R50 |
51.4% |
6.7% |
93% |
95% |
55% |
>99% |
| HEAT R60 |
62% |
6.7% |
90.4% |
93.1% |
51.2% |
>99% |
| HEAT R70 |
71% |
70% |
87.4% |
90.1% |
47% |
>99% |
HEAT HYBRID
Nano ceramic and metalized components are combined. It has low reflection. It has good heat protection and insulation effect with reasonable price.
| PRODUCT |
Visible Light transmittance |
Visible Light Reflectance |
IR cut off rate at 950nm |
IR cut off rate at 781~2500nm |
Total Solar Energy Rejected |
Ultraviolet
cut off ratio |
| HEAT H70 |
47.35% |
11.20% |
71.20% |
86% |
54.30% |
>99% |
ICE HYBRID
This is ideal combination of nano ceramic and 7 layer sputtered film. It is one of the best product in Filink.
| PRODUCT |
Visible Light transmittance |
Visible Light Reflectance |
IR cut off rate at 950nm |
IR cut off rate at 781~2500nm |
Total Solar Energy Rejected |
Ultraviolet
cut off ratio |
| ICE H95 |
46.9% |
14% |
95.3% |
94.4% |
59% |
>99% |
